Istio is a service mesh that transparently adds various capabilities like observability, traffic management and security to your distributed collection of microservices. It comes with various functionalities like circuit breaking, granular traffic routing, mTLS management, authentication and authorization polices, ability to do chaos testing etc.

In this post, we will explore on how to do canary deployments of our application using Istio.

What is Canary Deployment

Using Canary deployment strategy, you release a new version of your application to a small percentage of the production traffic. And then you monitor your application and gradually expand its percentage of the production traffic.

For a canary deployment to be shipped successfully, you need good monitoring in place. Based on your exact use case, you might want to check various metrics like performance, user experience or bounce rate.

Pre requisites

This post assumes that following components are already provisioned or installed:

• Kubernetes cluster

• Istio

• cert-manager: (Optional, required if you want to provision TLS certificates)

• Kiali (Optional)

Istio Concepts

For this specific deployment, we will be using three specific features of Istio's traffic management capabilities:

• Virtual Service: Virtual Service describes how traffic flows to a set of destinations. Using Virtual Service you can configure how to route the requests to a service within the mesh. It contains a bunch of routing rules that are evaluated, and then a decision is made on where to route the incoming request (or even reject if no routes match).

• Gateway: Gateways are used to manage your inbound and outbound traffic. They allow you to specify the virtual hosts and their associated ports that needs to be opened for allowing the traffic into the cluster.

• Destination Rule: This is used to configure how a client in the mesh interacts with your service. It's used for configuring TLS settings of your sidecar, splitting your service into subsets, load balancing strategy for your clients etc.

For doing canary deployment, destination rule plays a major role as that's what we will be using to split the service into subset and route traffic accordingly.

Application deployment

For our canary deployment, we will be using the following version of the application:

• httpbin.org: This will be the version one (v1) of our application. This is the application that's already deployed, and your aim is to partially replace it with a newer version of the application.

• websocket app: This will be the version two (v2) of the application that has to be gradually introduced.

Note that in the actual real world, both the applications will share the same code. For our example, we are just taking two arbitrary applications to make testing easier.

Our assumption is that we already have version one of our application deployed. So let's deploy that initially. We will write our usual Kubernetes resources for it. The deployment manifest for the version one application:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: httpbin
  namespace: canary
spec:
  replicas: 1
  selector:
    matchLabels:
      app: httpbin
      version: v1
  template:
    metadata:
      labels:
        app: httpbin
        version: v1
    spec:
      containers:
      - image: docker.io/kennethreitz/httpbin
        imagePullPolicy: IfNotPresent
        name: httpbin
        ports:
        - containerPort: 80

And let's create a corresponding service for it:

apiVersion: v1
kind: Service
metadata:
  labels:
    app: httpbin
  name: httpbin
  namespace: canary
spec:
  ports:
  - name: httpbin
    port: 8000
    targetPort: 80
  - name: tornado
    port: 8001
    targetPort: 8888
  selector:
    app: httpbin
  type

SSL certificate for the application which will use cert-manager:

apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: httpbin-ingress-cert
  namespace: istio-system
spec:
  secretName: httpbin-ingress-cert
  issuerRef:
    name: letsencrypt-dns-prod
    kind: ClusterIssuer
  dnsNames

And the Istio resources for the application:

apiVersion: networking.istio.io/v1alpha3
kind: Gateway
metadata:
  name: httpbin-gateway
  namespace: canary
spec:
  selector:
    istio: ingressgateway
  servers:
  - hosts:
    - canary.33test.dev-sandbox.fpcomplete.com
    port:
      name: https-httpbin
      number: 443
      protocol: HTTPS
    tls:
      credentialName: httpbin-ingress-cert
      mode: SIMPLE
  - hosts:
    - canary.33test.dev-sandbox.fpcomplete.com
    port:
      name: http-httpbin
      number: 80
      protocol: HTTP
    tls:
      httpsRedirect: true
---
apiVersion: networking.istio.io/v1alpha3
kind: VirtualService
metadata:
  name: httpbin
  namespace: canary
spec:
  gateways:
  - httpbin-gateway
  hosts:
  - canary.33test.dev-sandbox.fpcomplete.com
  http:
  - route:
    - destination:
        host: httpbin.canary.svc.cluster.local
        port:
          number: 8000

The above resource define gateway and virtual service. You could see that we are using TLS here and redirecting HTTP to HTTPS.

We also have to make sure that namespace has istio injection enabled:

apiVersion: v1
kind: Namespace
metadata:
  labels:
    app.kubernetes.io/component: httpbin
    istio-injection: enabled
  name

I have the above set of k8s resources managed via kustomize. Let's deploy them to get the initial environment which consists of only v1 (httpbin) application:

❯ kustomize build overlays/istio_canary > istio.yaml
❯ kubectl apply -f istio.yaml
namespace/canary created
service/httpbin created
deployment.apps/httpbin created
gateway.networking.istio.io/httpbin-gateway created
virtualservice.networking.istio.io/httpbin created
❯ kubectl apply -f overlays/istio_canary/certificate.yaml
certificate.cert-manager.io/httpbin-ingress-cert created

Now I can go and verify in my browser that my application is actually up and running:
